Fire Door Hinges – 3 Inch / 76mm – Grade 7 Ball Bearing (Sold as a Pair)

The Grade 7 Ball Bearing Fire Door Hinges are a high-quality solution designed to provide strength, smooth operation, and reliable performance for internal fire door installations. Tested to meet strict British Standards, these hinges help maintain fire door compliance while offering long-lasting durability.

Featuring a premium ball bearing mechanism, these hinges provide smoother door movement and improved resistance to wear over time. Suitable for standard internal domestic doors weighing up to 40kg, they are certified for FD30 fire doors and supplied as a pair with matching finish fixing screws.

Key Features

• Grade 7 ball bearing fire door hinges
• Suitable for standard internal domestic doors
• Suitable for doors weighing up to 40kg
• Tested and certified to BS EN 1634 for 30-minute fire doors
• BS EN 1935 performance tested to withstand 200,000 cycles
• CE 2812 and UKCA 1121 tested
• Ball bearing construction for smooth operation and enhanced durability
• Supplied as a pair
• Matching finish threaded screws supplied (Size 8 x 1 ¾")

Available Finishes

• Antique Brass
• Satin Chrome
• Satin Brass
• Black
• Polished Brass

Specifications

• Product Type: Fire Door Hinges
• Bearing Type: Ball Bearing
• Grade: Grade 7
• Fire Rating: FD30
• Size: 76mm x 51mm x 2mm
• Hinge Height: 3 inch / 76mm
• Height Range: 3 - 3.5 inch / 75 - 76mm
• Hinge Width: 2 inch / 51mm
• Profile: Square
• Maximum Door Weight: 40kg
• Testing Standards: BS EN 1634, BS EN 1935, CE 2812, UKCA 1121
